Product Name:

10 kg Hard Pendulum and 45 kg Soft Pendulum

Model No.:

10kg 45kg


Product Details

10 kg Hard Pendulum and 45 kg Soft Pendulum
Pendulum Shock Tests Device for Glass Panels for Electric Lifts


Related Standard:
GB 7588-2003 Safety rules for the construction and installation of electric lifts
EN 81-1 Safety rules for the construction and installation of lifts - Part 1: Electric lifts

Hard pendulum shock device
Height: 330± 15mm
Max diameter: 240±10mm
Weight: 10kg ± 0.1kg
Material: according to ISO standard
Filler: 3.5mm + 0.25mm

Soft pendulum shock device
Height: 330mm ± 15mm
Maximum diameter: 240mm±15mm
Weight: 45kg ± 0.5kg
Material: leather bag
Filler: diameter 3.5mm ± 1mm lead sand


Pendulum Shock Device of Electric Lifts

Pendulum Shock Device of Electric Lifts

Pendulum Shock Device of Electric Lifts


Yuanchen supply all kinds of testing equipment for safety glazing materials and PV module



All equipments design and produce according standard

Ten Years Experience in Production and Processing

Stock Supply/Complete Set of Glass Testing Equipment

Major Suppliers of China's Market Safety Glass Testing Equipment

OEM/ODM/Development, Design and Processing of Various Testing Equipment



Equipment List:

Ball Test Device

Pummel Test Device

Shot Bag 45kg/46kg

Impact Testing Frame

Head Form Test Device

PV Load Test Equipment

Pneumatic Tyres Device

Target Light Source Instrument

Anti Smashing GlassTest Frame

Pneumatic Tyres Impact Device

Insulating Glass Dew Point Meter

Crushing Pen for Tempered Glass

Hard/Soft Pendulum Shock Test for Lifts

Optical Distortion Measuring Instrument

Hardened Steel Ball 2260g/1040g/508g/227g

Laminated Glass High Temperature Test Oven

Mechanical load test equipment for PV Module

Tempered Glass Flatness Measuring Instrument

Impactor for building Glass and Metal Guardrail

Hard and Soft Body Impactors for Opaque Wall Components



Our Advantages:

Ten Years Experience in Production and Processing

Stock Supply/Complete Set of Glass Testing Equipment

Major Suppliers of China's Market Safety Glass Testing Equipment

OEM/ODM/Development, Design and Processing of Various Testing Equipment
